Digital Voltmeter DV-72

£28.72
Compact digital voltmeter for accurate AC voltage measurement up to 500 V. Features a bright 4-digit LED display, operates on 230 VAC with wide frequency compatibility (50/60 Hz), and offers reliable performance in demanding environments. Ideal for panel mounting and industrial applications.
In Stock

SKU: DV-72

1

This digital voltmeter is designed for precise monitoring of AC voltage in electrical panels and industrial systems. Operating at a rated voltage of 230 VAC, it supports a wide operating range from 0.8 × Un to 1.1 × Un and measures up to 500 VAC with high accuracy (±1% + digit). The bright 4-digit LED display ensures easy readability, while low power consumption (< 4 VA supply, < 1 VA measurement) enhances efficiency.

Built to perform reliably in harsh conditions, the unit operates within –5 °C to +50 °C and 15%–95% humidity (non-condensing). It offers IP20 device protection and IP00 connector protection, suitable for front panel mounting (tap connection). Available in two compact sizes — DV-72 (72 × 72 × 80 mm) and DV-96 (96 × 96 × 80 mm) — this voltmeter is an excellent choice for electrical panels, power monitoring systems, and control applications.
